SUPERMARINE SPITFIRE AND F-35B LIGHTNING II 'THEN AND NOW'

Supermarine Spitfire is probably the most famous British fighter from the Second World War. It was an all-metal machine with a low wing configuration, characteristic elliptical wings, a classic tail and a retractable landing gear. The prototype flight took place on March 5, 1936. The Spitfire proved to be the RAF's staple of the war, which continued to do well after the war, remaining in production for 10 years. The history of the Spitfire began on the drawing desk of RJ Mitchell, Supermarine's lead designer. The first machines went to RAF units in 1938, but when the Battle of Britain began in the summer of 1940, there were already 19 squadrons of modern fighters at the airfields - together with the slightly older Hurricanes of the Islands, 600 aircraft were defending. With the expansion of hostilities, the Spitfire served wherever the RAF operated in the Far East, North Africa and Italy, during the Normandy landings and fighting in France, and finally during the operation in Germany in 1945. For many Britons, he became a symbol of victory in World War II. This wonderful machine has at least a dozen production versions. The most important of them are, among others the first mass-produced Spitfire Mk.I powered by a 1030hp Rolls-Royce Merlin II engine. It was above all this machine that made such an excellent contribution to the Battle of Britain. Many versions of this model have been developed, including PR Mk IA (reconnaissance version) or PR.IG (armed reconnaissance version). Another interesting version was the Spitfire Mk.V with a Rolls-Royce Merlin 45 engine with 1440HP. Later, Merlin 50 engines were also assembled. Serial production of this version started in 1941 and was the RAF's response to the appearance of the Messerschmitt Bf-109F. Another very successful version is the Spitfire Mk.IX, powered by a Merlin 61 engine with a 4-blade propeller. It was created as an opponent to the Focke-Wulf Fw-190 and was put into production at the end of 1941. This version was modified many times and, for example, in 1944 it got a new gyro sight, an enlarged rudder or a different wing system. Another major version is the Spitfire Mk.XIV with a Rolls-Royce Griffon 61 engine and a five-bladed propeller. Serial production started in October 1943. One of the last series produced was the Mk.21 version. This version had a Griffon 61 engine, a strongly reinforced structure and sheathing, the wings were extended, increasing their flying surface. Mass production started in March 1945. Technical data (Mk.XIV version): length: 9.14m, wingspan: 11.23m, height: 3.05m, maximum speed: 717km / h, rate of climb: 18.5m / s, practical ceiling: 13,200m, range maximum: 1815 km, armament: fixed - 4 7.7mm machine guns and 2 20mm Hispano Mk II cannons, suspended - up to 225 kg of bombs.Lockheed Martin F-35 Lightning II (lightning) is a single-seat, single-engine multi-role fighter built by Lockheed Martin as a fifth generation machine, which is to meet the needs of the USAAF, US Navy, US Army and US Marine Corps. Originally the machine was called the X-35 JSF, but in 2006 it was changed to the F-35 Lightning II. Despite the fact that the main recipient will be the US government, the project is also co-financed by other countries, especially Great Britain, Italy and the Netherlands. The main contractors are: Lockheed Martin, Northrop Grumman and BAE Systems. The overriding goal of the JSF idea is to create a universal machine, produced for all types of armed forces, which will allow for far-reaching standardization of spare parts and a significant reduction in costs. Finally, three versions of the F-35 (A, B and C) are to be built, which will have more than three-quarters of the same elements. The main task of the F-35 of all versions is to attack land targets, perform the tasks of a battlefield plane, air combat and electronic combat. It should be noted that the F-35 is designed for conflicts of a low intensity, in contrast to its larger "relative" F-22. Which does not change the fact that thanks to the propulsion unit used (Pratt-Whitney F135 engines), avionics and Stealth properties, it is one of the most modern multi-role aircraft in the world. The first serial F-35 was made in February 2006. Until now (2013), 63 aircraft of this type have been built. Technical data (version F-35A): Maximum speed: 1930 km / h, maximum ceiling 18288 m, maximum range: 2220 km, armament: fixed - one four-barrel General Dynamics GAU-22 / A 25mm cannon, suspended - up to 8100 kg load.
